CAT5 RJ45 Network LAN Cable Tester
Specification:
• LCD : 4 x 16 characters big screen (valid visual field 61.6 x 25.2 mm)
• Type of Tester Cable : STP / UTP twin twisted cable, coaxial cable, telephone line
• Tester Port :
• Tester RJ45 master port (M), tester LOOPBACK RJ45 port (L), far-end recognizer RJ45 port (R).
• The extra BNC and RJ11 converters are used to measure and check the continuity of coaxial cable and telephone line
• Length Measurement of Twin Twisted Cable:
• Scope : 1350M (31,200 FT)
• Display : M or FT
• Length Calibration : User can set calibration factor by himself by a given length cable. The length of calibrating cable is more than 5M.
• Wire Sequence and Locating Cable Error : Check errors such as open circuit, short circuit, reverse connection, cross over or cross-talk interference.
• Locating Cable : Included 1 far-end passive test jack
• Use 4 x AA batteries (Not included)
• Item size : 180 x 80 x 40 mm
• The cable tester has CE-MARK
Package Include:
• 1X Unit
• 1X Far End jack
• 1X English manual
• Checks wiring error in 5E, 6E, coaxial and telephone line
• Check open circuit, short circuit, jumper wire, reverse connection or cross-talk interference
• Locates the wiring or connection error
• Measures cable length and determines the distance of open circuit and short circuit
• Dynamically calibrates cable length and makes length measurement as accurate as 97%25
• Simple and easy use, big screen to display test clear
• Portable unit with long battery life (wait-case 50 hours)
• Automatically time-delay shut off
• Measures length and pair with or without far-end recognizer
• Locates cable and there are 8 far-end passive test jacks (ID no.: ID1 – ID 8)
• Far-end recognize with prompting voice
• Self-checking function and automatically compensates any change in battery capacity or ambient temperature
• Single board computer software watchdog design
